DS-5005HV – BK Mini High-Speed Tail Servo
The BK DS-5005HV is a mini digital tail servo running on a 760 µs / 333 Hz signal, designed for 500-class RC helicopters. With a coreless motor and metal gears, it delivers ultra-fast tail response and exceptional holding power.
Main Features:
- High-voltage servo for 500-class helicopters
- 760 µs / 333 Hz tail signal for fast gyro compatibility
- Coreless motor and full metal gear train
- High precision and rapid response time
Technical Specifications:
| Specification | Value |
|---|---|
| Operating Voltage | 6V – 8.4V |
| Torque @ 6V | 4.16 kg·cm (57.7 oz·in) |
| Torque @ 7.4V | 5.00 kg·cm (69.4 oz·in) |
| Torque @ 8.4V | 5.50 kg·cm (76.3 oz·in) |
| Speed @ 6V | 0.040 sec/60° |
| Speed @ 7.4V | 0.035 sec/60° |
| Speed @ 8.4V | 0.030 sec/60° |
| Dimensions | 35 × 15 × 32 mm |
| Weight | 44 g (1.5 oz) |
| Motor Type | Coreless |
| Gear Type | Metal |
| Signal | 760 µs / 333 Hz |
High-speed HV tail servo designed for 500-class helicopters – fast, precise and durable.
DS-5005HV
5 Items
Data sheet
- Taille Servos
- Mini
- Type Servo
- Anticouple
Hélicoptère - Impulsions Servos
- 760 µs
- Fréquence Servos
- 333 Hz
- Type de moteur
- Coreless
- Tensions Servos
- 6,0 V
7,4 V
8,4 V
Specific References
- ean13
- 4717480601103
